The main function of
(1) distribution transformer monitoring: voltage, current, the voltage qualification rate, harmonics, flicker, transient overvoltage.
(2) protection of distribution transformer: undervoltage, overvoltage, overload, overheating protection
(3) electric information monitoring user: the user electric meter data
(4) summary of distribution transformer monitoring: meter data and running status table area
(5) residual current circuit breaker monitoring: residual current monitoring, state of residual current
(6) monitoring: terminal operation temperature, gas concentration, incoming and outgoing line switch, switch, transformer
(7): power load management custom closed-loop control, power set point control, remote control
(8) the power quality management: no dynamic reactive power compensation, three-phase unbalanced governance, harmonic control
(9) the safety protection: anti-theft alarm, abnormal information
(10) the communication function: GPRS uplink, downlink carrier
(11) the interaction management: handheld field management, local RS232 communication management.
On the basis of criteria:
5, "Q/GDW 615-2011 network intelligent distribution terminal specification and technical conditions";
6, DL/T 721-2000 "distribution automation system remote terminal";
7, Q/GDW 129-2005 "electric power load management system general technical conditions";
8, Q/GDW 130-2005 "electric power load management system data transmission protocol";
9, DL/698-1999 "low-voltage power user centralized meter reading system of technical conditions";
10, GB/T 20641-2006 "General requirements for low-voltage switchgear and control equipment shell body.";
11, Q/GDW 374.1-2009 "technical specification of power user electric energy data acquisition system: data acquisition terminals of special transformer technical specifications";
12, Q/GDW 375.1-2009 "type specification for information acquisition system of electric power user: data acquisition terminals of special transformer type specification";
13, Q/GDW, 374.2-2009 "power user electric energy data acquire system technical specification: centralized meter reading terminal specification"
14, Q/GDW 375.2-2009 "type specification for information acquisition system of electric power user: concentrator type specification";
15, Q/GDW 376.1-2009 "power user electric energy data acquire system communication protocol: master station and terminal communication protocol".
